Blue Star 1 way Cassette AC 2 Ton 2 Star Inverter In Only Rs. 97990/-
Model – OIA224SXUS
Performance Parameters Nominal Capacity (Tr) 2.0 Tr
Air Conditioner Type Inverter One – Way Cassette
Star Rating – As Per BEE 2 Star
(Rated) Voltage / Frequency / Phase 230 V / 50Hz / Single
Cooling Capacity (Min ~ Max) (Watt) 7000 (2490 ~ 7240)
Cooling Capacity (Min ~ Max) BTU/Hr 23884 (8495 ~ 24702)
Rated Cooling Capacity ( 50% Load) (Watt) 3500
Cooling Rated Power Input (Min ~ Max) (Watt) 2240 (595 ~ 2275)
Cooling Power Input (50% Load) (Watt) 808
ISEER4.00
Electricity Consumed In 1600 Hours. (Units/Year) 1355.89
Nominal Current (Cooling in Amps)/Running Current 9.7
Air Flow Volume (Wet CFM) (Turbo/ High/ Medium/ Low)620 / 560 / 480 / 380
Compressor, Refrigerant & Ambient Operations
Noise Level Indoor (Turbo/ High/ Medium/ Low) In dB(A)50 / 47 /45 / 40
Moisture Removal (Litres/Hour) 3.05
Compressor Type Inverter Rotary
Acoustic Jacket on Compressor Yes
Eco Friendly Refrigerant R32
Refrigerant Quantity (gms) 800
Ambient Temp Range (Cooling)°C 21°C to 52°C
User Interface – Remote Remote LCD Remote with Display
Product Dimensions, Weight & Input Power Supply
IDU Net Dimension (W X H X D ) mm 1202 X 135 X 473
IDU Gross Dimension (W X H X D ) mm 1462 X 250 X 538
Input Power Supply Outdoor Unit
Net Weight IDU (in Kg) 22
Gross Weight IDU (in Kg) 25.8
ODU Net Dimension (W X H X D ) mm 1015 X 721 X 332
ODU Gross Dimension (W X H X D ) mm 1075 X 755 X 410
Net Weight ODU (in Kg) 38.8
Gross Weigth ODU (in Kg) 42.8
Noise Level Outdoor In dB (A) 56
Power Supply to ODU Source(Core/Gauge) sqmm 4C * 2.5 sqmm
Cable from ODU to IDU (Communication Cable) m 3.5
Tube Size & Piping Capability
Suction Tube Size Outer Diameter Inch ( mm) 5/8″ (15.87 mm)
Liquid Tube Size Outer Diameter Inch ( mm) 1/4″ (6.35 mm)
Max Piping Capability Total (metre) 30
Max Piping Capability Vertical (metre) 15
Refrigerant Additional Charge Beyond 5M (g/m) 20
