AC 1.8 TR 3 Star One Way Cassette INVERTER
Model AC 1.8T CIC 21GTC3 1ZP
RATED VOLTAGE / FREQUENCY / PHASE 230 V / 50 Hz / 1 PHASE
TONNAGE CLASSIFICATION 1.76 TR
MAX COOLING CAPACITY (RATED COOLING CAPACITY) 6510 (6200)
POWER INPUT IN WATTS 1880
ISEER (STAR RATING) 4.37 (3 STAR)
ELECTRICITY CONSUMPTION ( 1600 HOURS ) UNITS PER YEAR 1099.42
RATED CURRENT (AMP) 8.6
AIR FLOW VOLUME (DRY CFM/DRY CMH) 930/1580
NOISE LEVEL INDOOR (HIGH/ MEDIUM / LOW) IN DB (A) 46 / 44 / 42
MODES DRY / COOL / AUTO / FAN / TURBO
TIMER ON / OFF YES
HORIZONTAL SWING (LEFT & RIGHT SWING MOVEMENT) AUTO
VERTICAL SWING (UP & DOWN SWING MOVEMENT) AUTO
AUTO RESTART WITH MEMORY FUNCTION YES
HYGIENE+ / BLOW (SELF CLEAN) YES
ANTI FREEZE YES
5 IN 1 CONVERTER YES
LOCK YES
CLOCK YES
AI TECH YES
FILTER CONFIGURATION PURE AIR FILTER
EVAPORATOR FINS HYDROPHILIC BLUE FINS
CONDENSER FINS BARE FINS
EXPANSION DEVICE IN ODU EEV
FRONT PANEL COLOUR (STRIP) WHITE
NET IDU DIMENSION (W X H X D) CM 118.0 X 17.0 X 44.8
GROSS IDU DIMENSION (W X H X D) CM 142.0 X 24.0 X 53.0
INPUT POWER SUPPLY OUTDOOR UNIT
NET WEIGHT IDU (KG) 15.8
GROSS WEIGHT IDU (KG) 21.7
NET ODU DIMENSION ( W X H X D) CM 78.0 X 54.0 X 31.0
GROSS ODU DIMENSION ( W X H X D) CM 88.5 X 61.5 X 41.7
NOISE LEVEL OUTDOOR IN DB(A) 56
NET WEIGHT ODU (KG) 28
GROSS WEIGHT ODU (KG) 32
COMPRESSOR TYPE TWIN ROTARY INVERTER
COMPRESSOR WARRANTY 5 YEAR
ACOUSTIC JACKET ON COMPRESSOR YES
REFRIGERANT R32
MAX AMBIENT TEMP (COOLING) 52
SUCTION TUBE SIZE OUTER DIAMETER INCHES (MM) 1/2″ (12.0)
LIQUID TUBE SIZE OUTER DIAMETER INCHES (MM) 1/4″ (6.0)
MAX PIPING CAPABILITY TOTAL (M) 15
MAX PIPING CAPABILITY VERTICAL (M) 5
REFRIGERANT ADDITIONAL CHARGE BEYOND 4M (G/M) 20
